A10 Moto 98-13 Road Glide Baja Designs LP6 Lighting Combo Kit

A10 MOTO
127066
Many in stock
Light Mounts/Combos
$349.99
Snap Logo Lease for as low as $/week Learn More

complete your look

$349.99
×
Total:
$0.00

Simply Put... The Absolute Brightest Light Kit Available for your Road Glide.

This Kit comes complete with a CNC Powder-coated Gloss Black Mounting Bracket, Hardware, and Our Spec Engineered Plug and Play Wire Harness all Made In the USA.

A10 Moto Harness:

The Original Harley LP6 Wire Harness is proudly engineered here in California. It's created to meet or exceed both manufacturers' quality standards from H.D. to Baja Designs.

Easy to use and 100% Plug and Play using relays and specially wired to "Eliminate" Additional Amp draw from your existing H.D. Harness. We have engineered this kit to be safe and effective in using only the "trigger" from your H.D. to signal the harness which controls 3 key functions. Daytime Running, Low and High Output.

Avoid costly and permanent damage to your bike's factory harness. When plugging in BIG HORSEPOWER Lighting you want the Best and Safest System to protect your investment. ALL Our H.D. Wire Kits come with a Life Time Warranty.

Installation Instructions: CLICK HERE

    Baja Designs LP6 Lights:

    The LP6 Pro is a 6-inch powerhouse featuring a total of 11,225 total lumens and of 200-degree spread of usable LED light thanks to the dedicated peripheral lighting of our patented Integrated Peripheral Technology (IPT). To keep your light performing at its highest potential, the LP6 integrates our proprietary Direct Ducted Cooling (DDC) technology. This feature allows air to travel through the front of the housing, over the rear heat sinks – drastically improving cooling capacity and performance. With an colored daytime running light, low power, and high-power mode, the LP6 easily fulfills all your lighting needs.

    The LP6 Pro is available in multiple patterns to suit your needs. The Driving/Combo pattern provide maximum trail coverage in a single light. The Driving/Combo pattern is equipped with both Driving (42 degrees) and spot (8 degrees) optics to provide you with a smooth blend of light for both near-field applications and distance (Lighting Zones, 1,2, 3). The Spot pattern is a longer and narrower 8-degree beam focus for illumination further down the trail or road (Lighting Zone 4 & 5) and is designed to be used in conjunction with additional wide cornering and/or driving/combo auxiliary lights.

    The addition of red, blue, or green backlight options alongside our original amber on the LP6 Pro gives enthusiasts the choice to customize their vehicle for shows, photo shoots or anywhere they want to bring attention.

    Disclaimer: Baja Designs LP series lights with red, blue, or green backlights are for EXHIBITION USE ONLY. Never use it on public roads to avoid confusion with law enforcement or emergency vehicles. The owner/driver is responsible for observing all highway equipment laws and safety regulations.

    • Satisfaction Guarantee – 30-Day Money Back Guarantee
    • Limited Lifetime Warranty – Complete Purchase Protection
    • uService – Replaceable Lenses And Optics
    • ClearView – All The Light, Right Where You Need It
    • MoistureBlock – Waterproof, Rain Proof, Submersible
    • CopperDrive – Safely Driving LEDs at 100%
    • 5000K Daylight – Less Driver Fatigue, Natural Color

    Enhance your Harley Davidson motorcycle’s visibility with A10 MOTO’s Performance Lighting Systems featuring the ultra-bright LP6, LP4, and other Baja Designs lights. Experience unparalleled illumination for safer, more enjoyable rides.
    A10 MOTO.

    What's Included:

    Qty Bracket Part Number / Description
    1 127066 Main Front Mounting Bracket
    1 127066-2LFT Left Side Light Bracket
    1 127066-2RHT Right Side Light Bracket
    1 127066-3 LP6 Rear Support Bracket
    1 127066-4 Front Tin Shield
    2 127066-5 Spacer Ring
    1 127066-6 Z Bend Center Stand Off
    No need to purchase an extra filler plate to complete the look!


    Hardware Included:

    QTY Hardware Description
    9
    1/4x20 grade 5 nylock nuts zinc
    9
    1/4" grade 5 washers zinc
    1
    1/4x20x1/2" Black Stainless Button Head
    4
    1/4" BlackStainless Washer
    1 1/4x20x3/4" grade 5 zinc bolt (for template only)
